BT3562 Battery Tester

BT3562 Battery Tester

6000.00 - 60000.00 INR/Piece

Product Details:

X

Price And Quantity

  • 5 Piece
  • 6000.00 - 60000.00 INR/Piece

Trade Information

  • 50 Piece Per Day
  • 2-30 Days

Product Description

We are engaged in supplying BT3562 Battery Hitester that is unmatched in terms of design and performance. This is a precision electronic device designed to help test the internal resistance and voltage of batteries. The device is suitable for testing small secondary batteries. It employs a cutting-edge four-terminal AC method in order to measure the internal resistance of batteries. Due to its superior design and efficient performance, we are seeing a huge demand for the BT3562 Battery Hitester in the marketplace.

Key Features :

  • Measure the voltage of battery packs up to 60 V
  • Production line testing of high-voltage battery packs and battery modules
  • Large (low-resistance) cell testing
  • Choice of PC interfaces for full remote operation
  • Note: The comparison threshold values depend on the battery manufacturer, type, and capacity, and these must be established by the user.

Basic specifications (Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)

Max. applied measurement voltage

+ 60 V DC rated input voltage
+ 70 V DC Max. rated voltage to earth

Resistance measurement ranges

3 mΩ (Max. display 3.1000 mΩ, resolution 0.1 μΩ) to 3000 Ω (Max. display 3100.0 Ω, resolution 100 mΩ), 7 ranges
Accuracy: 30 mΩ to 3000 Ω ranges, + 0.5% rdg. + 5 dgt. (Add + 3 dgt. for EX.FAST, or + 2 dgt. for FAST and MEDIUM)
3 mΩ range, + 0.5% rdg. + 10 dgt. (Add + 30 dgt. for EX.FAST, or + 10 dgt. for FAST, or + 5 dgt. for MEDIUM)
Testing source frequency: 1 kHz + 0.2 Hz, testing current: 100 mA (3 mΩ range) to 10 μA (3000 Ω range)
Open-circuit Voltage: 25 V peak (3/30 mΩ ranges), 7 V peak (300 mΩ range), 4 V peak (3 Ω to 3000 Ω ranges)

Voltage measurement ranges

6 VDC (resolution 10 μV) to 60 VDC (resolution 100 μV), 2 ranges


Accuracy: + 0.01% rdg. + 3 dgt. (Add + 3 dgt. for EX.FAST, or + 2 dgt. for FAST and MEDIUM)

Display

31000 full digits (resistance), 600000 full digits (voltage), LED

Sampling rate

Four steps, 4 ms (Extra-FAST), 12 ms (FAST), 35 ms (Medium), 150 ms (Slow) (Typ., sampling time depends on supply frequency settings and function.)

Measurement time

Response time + sampling rate, approx. 10 ms for measurements
(Response time depends on reference values and the measurement object.)

Comparator functions

Judgment result: Hi/IN/Lo (resistance and voltage judged independently)
Setting: Upper and lower limit, Deviation (%) from reference value
Logical ANDed result: PASS/FAIL, calculates the logical AND of resistance and voltage judgment results.
Result display, beeper, or external I/O output, Open-collector (35 V, 50 mA DC max.)

Analog output

Measured resistance (displayed value, from 0 to 3.1 V DC, -01 suffix models only)

Interfaces

External I/O, RS-232C, Printer (RS-232C), GP-IB (-01 suffix models only)

Power supply

100 to 240 VAC, 50/60 Hz, 30 VA max.

Dimensions and mass

215 mm (8.46 in) W X 80 mm (3.15 in) H X 295 mm (11.61 in) D, 2.4 kg (84.7 oz)

Accessories

Instruction manual X 1, Power cord X 1
