DT4252 Digital Multimeter Card Hitester is a precision electronic device designed to measure certain quantities such as voltage, current, resistance, among others. The card hitester has got the capability of standing voltage fluctuation, noises, heat, and unfavorable factors that can degrade the performance of the device. It is extensively used in the electrical and electronic industry. Due to its longevity and high operational reliability, we are seeing a huge demand for the DT4252 Digital Multimeter Card Hitester in the marketplace.
Key Features :
Basic specifications (Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)Regarding DMM Accuracy Due to the many ranges and functions available in a DMM, only the basic accuracy is indicated for reference. Please refer to the individual catalogs for detailed accuracy information.
DC Voltage range | 600.0 mV to 1000 V, 5 ranges Basic accuracy: +0.3 % rdg. +5 dgt. |
---|---|
AC Voltage range | 6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz - 1 kHz |
AUTO AC/DCV | N/A |
Resistance range | 600.0 Ω to 60.00 MΩ, 6 ranges, Basic accuracy: +0.7 % rdg. +5 dgt. |
DC Current range | 6.000 A / 10.00 A, 2 ranges, Basic accuracy: +0.9 % rdg. +5 dgt. |
AC Current range | 6.000 A / 10.00 A, 2 ranges, Basic accuracy 40 - 500 Hz : +1.4 % rdg. +3 dgt. (True RMS, crest factor 3, 40 Hz to 1 kHz) |
AC Current range (use with Clamp on probes) | N/A |
Voltage detection (50/60 Hz) | N/A |
Capacitance range | 1.000 μF to 10.00 mF, 5 ranges, Basic accuracy: +1.9 % rdg. +5 dgt. |
Frequency range | AC V, AC A measurement: 99.99 Hz (5 Hz or more) to 9.999 kHz, 3 ranges, 99.99 kHz (only for AC V) Basic accuracy: +0.1 % rdg. +1 dgt. |
Continuity check | Continuity threshold [ON]: 25 Ω or less (Indicate buzzer sound, red LED), [OFF]: 245 Ω or more Response time: 0.5 ms or more |
Diode test | Open terminal voltage: 5.0 V or less, Testing current 0.5 mA or less, |
Other functions | Filter function, Display value hold, Auto hold, Max/Min/Average value display, Relative display, Auto-power save, USB communication (option) |
Display | Main and Sub displays: 4-digits LCD, max. 6000 digits, bar graph |
Display refresh rates | 5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 time/s, Temperature: 1 time/s ) |
Power supply | LR03 alkaline batteries X 4, Continuous use: 130 hours (back light OFF) |
Dimensions and mass | 84 mm (3.31 in)W X 174 mm (6.85 in)H X 52 mm (2.05 in)D, 390 g (13.8 oz) (with batteries and holster) |
Accessories | Test lead L9207-10 X 1, Holster X 1, Instruction manual X 1, LR03 alkaline battery X 4 |
|
|
![]() |
