DT4254 Digital Multimeter Card Tester

DT4254 Digital Multimeter Card Tester

4000.00 - 40000.00 INR/Piece

Product Details:

X

Price And Quantity

  • 1 Piece
  • 4000.00 - 40000.00 INR/Piece

Trade Information

  • 4 Piece Per Week
  • 4 Week

Product Description

DT4254 Digital Multimeter Card Hitester is one of the most sought-after devices in the marketplace owing to its user-friendly design and longevity. It is a pocket-sized, compact digital device designed for the general measurement of current, voltage, resistance, and a few others. The card Hitester is extensively used in the electrical and electronic industry. Owing to steadfast plastic housing and resilience, the offered DT4254 Digital Multimeter Card Hitester is sure to last for an extended period of time.

Key Features :

  • The voltage measurement model, which is ideal for solar power system and power equipment management, measures up to 1700 V DC (*1) during open voltage inspections (DT4254)
  • Prevents accidents with clamp-on sensor-based current measurement (DT4254, DT4255)
  • Voltage detection function (DT4254, DT4255)
  • Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms)
  • Broad -25oC (-13oF) to 65oC (149oF) operating temperature range (DT4254, DT4255)
  • Dual display lets you check voltage and frequency simultaneously

Basic specifications (Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)

DC Voltage range

600.0 mV to 1500 V (*1) 5 ranges, Basic accuracy: +0.3 % rdg. +3 dgt.

AC Voltage range

6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz to 1 kHz
Basic accuracy 40 - 500 Hz : +0.9 % rdg. +3 dgt. (True RMS, crest factor 3)

AUTO AC/DCV

Yes

Resistance range

N/A

DC Current range

N/A

From 4 to 20mA Percentage conversion display

N/A

AC Current range (use with Clamp on probes)

N/A

Temperature (thermocouples)

N/A

Voltage detection

Hi: AC40 V to 600 V, Lo: AC80 V to 600 V

Capacitance range

N/A

Frequency range

99.99 Hz to 99.99 kHz, 4 ranges (limited by the minimum detectable voltage), Basic accuracy: +0.1 % rdg. +1 dgt.

Continuity check

N/A

Diode test

N/A

Other functions

Filter function, Display value hold, Auto hold, Max/Min/Average value display, Relative display, Auto-power save, USB communication (option)

Display

Main and Sub displays: 4-digits LCD, max. 6000 digits, bar graph

Display refresh rates

5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 time/s)

Power supply

LR03 alkaline batteries X 4, Continuous use: 130 hours (backlight OFF)

Dimensions and mass

84 mm (3.31 in)W X 174 mm (6.85 in)HX 52 mm (2.05 in)D,
390 g (13.8 oz) (including batteries and holster)

Accessories

Test lead L9207-10 X 1, Holster X 1, Instruction manual X 1, LR03 alkaline battery X 4
