DT4282 Digital Multimeter Card Multimeter

DT4282 Digital Multimeter Card Multimeter

4000.00 - 40000.00 INR/Piece

Product Details:

X

Price And Quantity

  • 1 Piece
  • 4000.00 - 40000.00 INR/Piece

Trade Information

  • 4 Piece Per Week
  • 4 Week

Product Description

We are instrumental in supplying the best in class DT4282 Digital Multimeter Card Hitester that is widely acclaimed among our customers owing to its high build quality, pocket-sized design, and longevity. The device is typically used in the electrical and electronic industry for the general testing of varied instruments and electrical systems. The device helps measure values of current, voltage, resistance, among others. Due to its ergonomic design and user-friendly operation, it is easy to work with and maintain. DT4282 Digital Multimeter Card Hitester can be purchased from us at a cost-effective price.

Key Features :

  • 60000 count, 5-digit display, high-resolution measurements
  • +0.025% DC V basic accuracy, wide 20 Hz to 100 kHz AC V frequency characteristics
  • Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms)
  • Includes multiple measurement functions such as DC+ACV, temperature, capacitance, and frequency
  • Terminal shutter mechanism (prevents erroneous test lead insertion)
  • Measure up to 10A with direct input (DT4282 only)
  • Dual display lets you check voltage and frequency simultaneously
  • Magnetic strap (optional)
  • Rear kickstand
  • Store probes at the back of the tester
  • Identify excessively high input with a red screen backlight
  • Robust design capable of withstanding a drop from a height of 1 m
  • USB communications function supports PC measurements (optional)
  • Broad -15 (5oF) to 55oC (131oF) operating temperature range


Basic specifications (Accuracy guaranteed for 1 year)Regarding DMM Accuracy Due to the many ranges and functions available in a DMM, only the basic accuracy is indicated for reference. Please refer to the individual catalogs for detailed accuracy information. * Zero-suppression: For small inputs below the guarantee range, zero is effectively displayed.


DC Voltage range

60.000 mV to 1000.0 V, 6 ranges, Basic accuracy: +0.025 % rdg. +2 dgt.

AC Voltage* range

60.000 mV to 1000.0 V, 6 ranges, Frequency characteristics: 20 Hz - 100 kHz
Basic accuracy 45 - 65 Hz : +0.2 % rdg. +25 dgt. (True RMS, crest factor 3)

DC + AC Voltage* range

6.0000 V to 1000.0 V, 4 ranges, Frequency characteristics: 20 Hz - 100 kHz
Basic accuracy 45 - 65 Hz : +0.3 % rdg. +30 dgt. (True RMS, crest factor 3)

Resistance range

60.000 Ω to 600.0 MΩ, 8 ranges, (Conductance: 600.00 nS, DT4282 only)
Basic accuracy: +0.03 % rdg. +2 dgt.

DC Current range

600.00 μA to 10.000 A, 6 ranges, Basic accuracy: +0.05 % rdg. +5 dgt.

AC Current* range

600.00 μA to 10.000 A, 6 ranges,
Basic accuracy 45 - 65 Hz : +0.6 % rdg. +5 dgt. (True RMS, crest factor 3)
Frequency characteristics: 20 Hz - 20 kHz (at 600 μA to 600 mA range)

AC Current* range (use with Clamp on probes)

N/A

Peak

DC V measurement: Signal width 4 msec or more (single), 1 msec or more (repeated)
AC V, DC/AC A measurement:
Signal width 1 msec or more (single), 250 μsec or more (repeated)

Capacitance range

1.000 nF to 100.0 mF, 9 ranges, Basic accuracy: +1.0 % rdg. +5 dgt.

Continuity Check

Continuity threshold: 20/50/100/500 Ω, Response time: 10 ms or more

Diode test

Open terminal voltage: 4.5 V or less, Testing current 1.2 mA or less, Threshold of forward voltage: 0.15 V to 3 V, seven stages

Frequency range

AC V, DC+AC V, AC A measurement, at pulse width 1 μs or more (50 % duty ratio)
99.999 Hz (0.5 Hz or more) to 500.00 kHz, 5 ranges, +0.005 % rdg. +3 dgt.

dB conversion

Standard impedance setting (dBm), 4 Ω to 1200 Ω, 20 stages
Display dB conversion value of AC voltage (dBV)

Temperature (thermocouples)

K: -40.0 °C to 800.0 oC (-40.0 oF to 1472.0 oF)
Add accuracy of the Thermocouple probe to main unit accuracy: +0.5 % rdg. +oC

Other functions

Filter function (Remove harmonic noise, use only at 600 VAC, 1000 VAC ranges), Display value hold, Auto hold, Max/Min value display, Sampling select, Relative display, Measurement memory (400 data), Auto-power save, USB communication (option), 4-20 mA % conversion

Display

Main and Sub displays: 5-digits LCD, max. 60000 digits

Display refresh rates

5 times/s (Capacitance measurement: 0.05 to 2 times/s, depending on measured value, Temperature: 1 time/s )

Power supply

LR6 (AA) alkaline batteries X 4, Continuous use: 100 hours

Dimensions and mass

93 mm (3.66 in) W X 197 mm (7.76 in) HX 53 mm (2.09 in) D, 650 g (22.9 oz) (with test leads holder and batteries)

Accessories

Test Lead L9207-10 X 1, Instruction Manual X 1, LR6 Alkaline Battery X 4
